Nidek Nuvo Lite Mark 5 Compact Oxygen Concentrator (Model 525): A Complete Guide
An ultra-compact, ultra-quiet stationary concentrator built for low-flow continuous therapy — 12 flow settings from 0.125 to 5.0 LPM, rapid RPSA startup, and just 32 pounds of net weight.
Not every continuous-flow oxygen prescription calls for high output — many patients, including pediatric cases, need precise low-flow settings alongside quiet, energy-efficient operation. The Nidek Nuvo Lite Mark 5 (Model 525) is built specifically for that low-flow range.
Delivering continuous-flow oxygen across 12 settings from 0.125 to 5.0 LPM at 90% (+6.5%/-3.0%) purity, the Nuvo Lite uses Nidek’s proprietary Rapid Pressure Swing Absorption (RPSA) technology to reach full therapeutic concentration in under 3 minutes, all while operating at an ultra-quiet ~40 dBA.
Engineered by Nidek Medical Products, Inc.
The Nuvo Lite Mark 5 is manufactured in the United States by Nidek Medical Products, Inc. and is backed by a 3-year limited manufacturer warranty. As a Class II FDA-regulated medical device, it is available strictly by prescription. This listing covers Model 525, which comes standard with Nidek’s integrated OCSI oxygen purity monitor — Model 520 does not include this sensor.
Nidek Nuvo Lite Mark 5 (Model 525)
Nidek Nuvo Lite Mark 5 Compact Oxygen Concentrator
An ultra-compact, energy-efficient stationary oxygen concentrator delivering continuous flow across 12 settings from 0.125 to 5.0 LPM. Nidek’s proprietary RPSA technology reaches full therapeutic 90% purity in under 3 minutes from a cold start. Comes standard with Nidek’s integrated OCSI purity monitor, a single-knob lockable flowmeter, a reinforced metal outlet nozzle to prevent connector shear damage, and accessible rear-panel filter maintenance. Operates at an ultra-quiet ~40 dBA with a low average power draw of ~330W.
Complete Spec Sheet
| Specification | Detail |
|---|---|
| Brand / Manufacturer | Nidek Medical Products, Inc. |
| Model | Nuvo Lite Mark 5 (Model 525 with OCSI) |
| Classification | Ultra-Compact Stationary Oxygen Concentrator |
| FDA Status | Class II Medical Device — Prescription (Rx) Required |
| HCPCS Code | E1390 |
| Flow Range | 0.125–5.0 LPM Continuous Flow (12 steps) |
| Outlet Pressure | 7 PSIG |
| Oxygen Concentration | 90% (+6.5% / -3.0%) across all flow settings |
| Purity Monitor | Integrated OCSI — included standard |
| Power | 115 VAC / 60 Hz (~330W average draw) |
| Sound Level | ~40 dBA average |
| Dimensions | 23.0"H x 14.0"W x 9.0"D |
| Weight | ~32.0 lbs (14.5 kg) |
| Origin / Warranty | Made in USA — 3-Year Limited Manufacturer Warranty |
Clinical Selection Note: Equipment must be selected according to prescribed flow rate and delivery requirements. Always cross-reference device capabilities with your physician’s prescription.
Who Is the Nuvo Lite Mark 5 Typically Prescribed For?
The Nuvo Lite is well suited to patients whose prescribed flow rate falls in the low-to-standard range — including pediatric and adult continuous oxygen protocols requiring precise low-flow settings down to 0.125 LPM. Its ultra-quiet operation and compact 32 lb chassis also make it a strong fit for home health placements and overnight care where acoustic disruption and space are concerns. As with any oxygen device, the appropriate flow rate should be determined by your physician based on your specific prescription.
Adding the Nuvo Lite Mark 5 to the EnhDme-Pro catalog gives physicians and facilities a precise, ultra-quiet low-flow option to complement our high-flow Nidek Nuvo 8 and Nuvo 10 listings.
Frequently Asked Questions
What is the difference between Nuvo Lite Model 525 and Model 520?
Model 525 includes the integrated Oxygen Concentration Status Indicator (OCSI), which continuously monitors gas purity and triggers alerts if oxygen levels drop below threshold. Model 520 does not include this monitor. This post covers Model 525.
How quickly does RPSA technology reach therapeutic oxygen concentration on startup?
Thanks to Rapid Pressure Swing Absorption (RPSA) technology, the Nuvo Lite reaches its full therapeutic oxygen concentration level of 90% in under 3 minutes from initial power-on.
What prescription documentation is required before an order ships?
Per FDA Class II medical device regulations, orders for the Nidek Nuvo Lite Mark 5 require a valid prescription or medical license specifying continuous-flow oxygen settings prior to compliance verification and shipment release.
