Nidek Nuvo Nano Portable Oxygen Concentrator
Nidek Nuvo Nano Ultra-Lightweight Portable Oxygen Concentrator (Model 855)
Pulse Dose (Settings 1ā5) up to 1,000 mL
4.7 lbs (2.1 kg) with Battery
FAA Commercial Air Approved
Executive Product Overview
The Nidek Nuvo Nano (Model 855) is an ultra-lightweight, American-made portable oxygen concentrator (POC) weighing just 4.7 pounds. Engineered for ambulatory patients, mobile care networks, and transport logistics, it supplies breath-actuated pulse-dose oxygen across five settings (210 to 1,000 mL/min) with oxygen concentrations reaching up to 96%.
Featuring a synchronized inspiratory trigger that operates across respiratory rates of 10 to 40 breaths per minute, the Nuvo Nano includes an Auto-Pulse backup safety system that automatically delivers pulsed oxygen if breath activity pauses. The unit features a backlit 2.8-inch color LCD display, operates on AC, DC vehicle, or rechargeable lithium-ion battery power, and is fully FAA-approved for commercial aviation.
Battery Runtime Performance Portfolio
Operational runtime estimates across pulse settings utilizing the standard quick-swap 14.5V lithium-ion battery pack:
| Pulse Setting | Minute Volume Output | Max Estimated Battery Runtime | Recharge & Operational Notes |
|---|---|---|---|
| Setting 1 | 210 mL/min | Up to 3.5 Hours | Recharges in under 4 hours via AC or DC vehicle power. |
| Setting 2 | 420 mL/min | Up to 3.25 Hours | Operates and recharges concurrently while connected to power. |
| Setting 3 | 630 mL/min | Up to 2.5 Hours | Ideal for moderate physical ambulation. |
| Setting 4 | 840 mL/min | Up to 2.15 Hours | Supports elevated oxygen demand during transport. |
| Setting 5 | 1,000 mL/min | Up to 1.5 Hours | Maximum pulse bolus output for high-demand activity. |
Key Performance & Operational Features
- Ultra-Lightweight Profile (4.7 lbs): Minimal weight burden for mobile patients and transport personnel.
- Pulse-Dose Settings 1ā5 (210ā1,000 mL/min): Precise breath-actuated bolus delivery synchronized with inspiratory onset.
- Auto-Pulse Backup Protocol: Automatically delivers oxygen pulses if no active breath is detected.
- Backlit 2.8ā³ Color LCD Screen: Displays real-time battery duration in minutes, pulse settings, and diagnostic status.
- FAA Commercial Aviation Compliant: Assembled in the USA and approved for commercial airline travel.
- AC/DC Vehicle Power Charging: Recharges concurrently in vehicle 12V DC ports or standard AC wall outlets.
- Easy-Access Sponge Intake Filter: Tool-free exterior sponge intake filter pops out for quick weekly maintenance.
Complete Technical Specifications
| Brand / Manufacturer | Nidek Medical Products, Inc. |
|---|---|
| Model Designation | Nuvo Nano (Model 855) |
| Product Classification | Ultra-Lightweight Portable Oxygen Concentrator |
| FDA Regulatory Status | Class II Medical Device | Prescription (Rx) Required |
| Delivery Mode & Output | Pulse Dose (Settings 1ā5) | Max Output: 1,000 mL/min |
| Oxygen Purity Concentration | 87.0% to 96.0% across all pulse settings |
| Sound Output Level | ~49 dBA at Setting 2 |
| Dimensions & Weight | 8.3ā³ W x 3.5ā³ D x 6.5ā³ H | Net Weight: 4.7 lbs (2.1 kg) with battery |
| Operating Power | AC Power (100ā240V); DC Power (12ā19V); Li-Ion Battery (14.5V, 6.8Ah) |
| Country of Origin | Made in USA |
| Included Accessories | Unit, Li-Ion battery, carrying case, shoulder strap, AC/DC adapters, manual |
Facility Procurement & Risk Mitigation Insight
Standardizing patient transport fleets on the American-made Nidek Nuvo Nano (Model 855) provides lightweight mobility without sacrificing diagnostic visibility. The backlit 2.8-inch color display simplifies staff audits of remaining runtime, while the Auto-Pulse backup safety system mitigates apneic risks during patient transport.
Product & Compliance FAQs
Q: Can the Nidek Nuvo Nano be used with a bubble humidifier bottle?
A: No. Humidifier bottles are restricted to stationary continuous-flow systems. Pulse-dose POCs output instantaneous gas boluses on inhalation and cannot build the line pressure necessary to push oxygen through water, which will trigger flow error alarms.
Q: Can the Nuvo Nano operate and recharge in a vehicle?
A: Yes. The included DC power cable plugs into standard 12V vehicle outlets, allowing the unit to deliver oxygen on all 5 settings while simultaneously charging the internal battery.
Q: What prescription verification is required prior to order dispatch?
A: Per FDA Class II medical device regulations, orders for the Nidek Nuvo Nano require a valid prescription or medical license specifying pulse-dose oxygen settings prior to compliance verification and shipment release.
B2B Procurement Disclaimer: Technical specifications, flow ratings, and regulatory guidelines are compiled from Nidek Medical manufacturer standards. Facilities are responsible for verifying valid prescription documentation prior to patient deployment.
